Trimethylsilyl Blocking Agent
Used as a protecting group for reactive hydrogens in alcohols, amines, thiols, and carboxylic acids. Organosilanes are hydrogen-like, can be introduced in high yield, and can be removed under selective conditions. They are stable over a wide range of reaction conditions and can be removed in the presence of other functional groups, including other protecting groups. The tolerance of silylated alcohols to chemical transformations summary is presented in Table 1 of the Silicon-Based Blocking Agents brochure.
Alkyl Silane - Conventional Surface Bonding
Aliphatic, fluorinated aliphatic or substituted aromatic hydrocarbon substituents are the hydrophobic entities which enable silanes to induce surface hydrophobicity. The organic substitution of the silane must be non-polar. The hydrophobic effect of the organic substitution can be related to the free energy of transfer of hydrocarbon molecules from an aqueous phase to a homogeneous hydrocarbon phase. A successful hydrophobic coating must eliminate or mitigate hydrogen bonding and shield polar surfaces from interaction with water by creating a non-polar interphase. Although silane and silicone derived coatings are in general the most hydrophobic, they maintain a high degree of permeability to water vapor. This allows coatings to breathe and reduce deterioration at the coating interface associated with entrapped water. Since ions are not transported through non-polar silane and silicone coatings, they offer protection to composite structures ranging from pigmented coatings to rebar reinforced concrete. A selection guide for hydrophobic silanes can be found on pages 22-31 of the Hydrophobicity, Hydrophilicity and Silane Surface Modification brochure.
Trimethylchorosilane; Chlorotrimethylsilane; Trimethylsilyl chloride; TMCS
Boiling Point: 57.6°
EINECS Number: 200-900-5
Melting Point: -57.7°
Molecular Weight: 108.64
Alternative Name: TMCS
Specific Gravity: 0.8580
Flashpoint: -27°C (-17°F)
HMIS Key: 3-4-2-X
Hydrolytic Sensitivity: 8: reacts rapidly with moisture, water, protic solvents
Refractive Index: 1.3885
Application: Review of synthetic utility.1
Review on organosilane protecting groups.2
Enhances Claisen rearrangement.3
Enhances the deprotection of tBOC-protected amino acids.4
Enhances ethylene glycol ketalization reaction.5
Catalyzes the formation of chlorohydrin esters from diols.6
Reviewed as water scavenger in reactions of carbonyl compounds.7
Facilitates Michael additions.8
Reference: 1. Handbook of Reagents for Organic Synthesis, Reagents for Silicon-Mediated Organic Synthesis, Fuchs, P. L. Ed., John Wiley and Sons, Ltd., 2011, p. 170-182.
2. Larson, G. L. “Silicon-Based Blocking Agents” Gelest, Inc. 2014.
3. Snider, B. B.; Hawryluk, N. A. Org. Synth. 2000, 2, 635.
4. Chen, B. C. et al. J. Org. Chem. 1999, 64, 9294.
5. Chan, T. H. et al. Synthesis 1983, 203.
6. Eras, J. et al. J. Org. Chem. 2002, I, 8631.
7. Volochnuk, D. M. et al. Synthesis 2009, 3719.
8. Xu, L. W. et al. Chem. Commun. 2003, 2570.
Fieser: F&F: Vol. 1, p 1232; Vol. 2, p 435; Vol.3, p 310; Vol. 4, p 32, p 537; Vol.5, p 709; Vol. 6, p 25; Vol. 7, p 66; Vol. 8, p 107; Vol. 9, p 112; Vol. 10, p 96; Vol. 11, p 125; Vol. 12, p 126; Vol. 13, p 165; Vol. 14, p 175; Vol. 15, p 89; Vol. 16, p 85; Vol. 17, p 79; Vol. 19, p 374; Vol. 20, p 348, p 380, p 404; Vol.21, p 453.
Additional Properties: 395Dipole moment: 2.09 debyeSurface tension: 17.8 mN/m?Hcomb: -714 kcal/moleCritical temperature: 224.6°?Hform: -84.5 kcal/moleCritical pressure: 31.6 atm?Hvap: 6.6 kcal/moleSpecific heat: 0.42 cal/g/°Coefficient of thermal expansion: 1.2 x 10-3Most economical and broadly used silylation reagentVapor pressure, 20°: 190 mmVapor pressure, 50°: 591 mm
